Оборудование для выгрузки цемента

CAR UNLOADING EQUIPMENT OFFER CEMENT AUGER FOR CEMENT CAR UNLOADING – CAPACITY 150 TPH – LENGTH 10,000 MM – DIAMETER 457 MM Removable tubular auger, highly efficient even in intermittent applications. Ø 457 mm, length 10 m, with a variable-inclination spiral, coaxial gearbox R 1/7. Capacity 150 tons/hour. Universal inlet. – CEMENT BUCKET ELEVATOR 25.5 m - 150 m3/hour – RUNNING PARAMETERS: Advance capacity 150 m3/hour Factor Filling: 71% Speed: 1.2 m/s Roller Distance: Approx. 25,500 mm Inlet-Outlet Distance: 23,000 mm The COMMAND COLLECTOR is constructed from a frame with an electric-welded structure consisting of sheet metal and Fe 360 ​​steel construction. It has integrated supports for the shaft and bottom flange, for connecting to the top flanges and cylindrical barrels, and for connecting the lid to the cylindrical barrels. The discharge door has a retractable wrench made of special steel to prevent loss and is equipped with an inspection hatch. The lid consists of two parts, completely covered with a rubber, sound-absorbing coating, and can be disassembled for servicing and inspecting the entire loading group, as well as for mounting and dismounting the belt. The drive shaft is made of 38NiCrMo4 steel, hardened and tempered, shaped to support the transmitted loads of the belt and drive unit. Inspection hatches are manufactured in accordance with European CE standards, facilitating opening of the entire drive unit. The return drum in the grate is made of C45 steel mounted on an electrowelded structure made of Fe360 sheet metal. The loading hopper is equipped with anti-rust steel. The return shaft is made of C45 steel, in accordance with DIN 17200, and is shaped to support the return drum from impacts caused by the material recess at the bottom. Material lifting buckets are manufactured in accordance with DIN 15234, specially designed for cement, made of Fe430 steel, with specially hardened edges to limit losses. The safety and control unit has four microcomputers to monitor the 6O-3OD belt slip. All bolts are galvanized to DIN 931 grade 8.8. DRYBATCH 70 S.M. DUST EXTRACTOR WITH RECHARGEABLE FUEL, with a recovery auger. The Euro DRYBATCH F70 filter has the following technical specifications: Filtration surface area: 70 m³. 11 kW (15 hp) centrifugal "silent" fan. 72 filter elements arranged in three rows. Filter cleaning system with compressed air supplied in a counter-current flow at a pressure of 5 to 6 bar. CAR UNLOADING STATION: The car unloading station consists of: - 50 m³ hopper. - 2 vibrators, 200 kg each. - 2 augers, 323 mm in diameter, with 3000 mm extractors under the hopper. - 20 x 20 mm vibrating net frame above the hopper with an independent vibrator. - 8 loading chambers with compression. INTEGRAL LOADING HOPPER COATING: Integral loading hopper cover: Completely constructed of steel structures, fully galvanized and painted on the outside, complete with a drain. Dimensions: 10,000 x 6,000 mm Not included in the delivery and supplied at the Buyer's discretion: interior lighting on the roof, concrete curb, curb fixing plates, and hardware. Price depends on the configuration. Available upon request.
